Hangzhou Epsole Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of foam cutting machine in China. We warmly welcome you to buy high quality foam cutting machine for sale here from our factory. Good service and reasonable price are available.
EPS Foam Cutting Machine – Precision Hot Wire Cutting for Insulation & Packaging
The EPS foam cutting machine is a specialized industrial hot wire cutter designed to precisely cut expanded polystyrene (EPS), extruded polystyrene (XPS), and polyurethane (PU) foam blocks into sheets, strips, and custom shapes. It is the essential downstream equipment following block molding, converting raw foam blocks into finished insulation boards, packaging materials, and construction components.
At Epsole, our foam cutting machines are engineered with heavy-duty steel frames, precision linear guides, stepless speed control (0–4 m/min) , and NiCr 80/20 nickel-chromium cutting wire for extended service life. Whether you need a horizontal cutter for high-volume sheet production or a vertical cutter for block sizing, our machines deliver ±0.5mm cutting accuracy and consistent performance for wholesalers and manufacturers worldwide.
| Parameter | Epsole Machine | Industry Benchmark | Customer Value |
|---|---|---|---|
| Cutting Precision | ±0.5mm | ±0.5mm – ±2.0mm | Reduces secondary finishing; improves product quality |
| Cutting Speed | 0–4 m/min (stepless adjustable) | 0–3 m/min | Higher throughput; faster order fulfillment |
| Cutting Wire Material | NiCr 80/20 (Cr20Ni80) | Iron-chromium-aluminum | 30%+ longer wire life; lower consumable cost |
| Transformer Capacity | 3 KVA (multi-tap, 0–70V adjustable) | 3–10 KVA | Supports up to 20 heating wires for parallel cutting |
| Control System | Industrial PC + Windows + Cutting Software | Manual or basic control | CAD-to-cut workflow; one-touch operation |
| Frame Construction | Heavy-duty steel + aging heat treatment | Standard welded steel | No deformation under long-term operation |
| Max Workpiece Size | Customizable (up to 4000×1500×1250mm) | Varies | Adapts to different block sizes and production needs |
| Certifications | CE + ISO 9001:2015 | Varies by supplier | Hassle-free customs clearance; global compliance |
Core Advantages
High-Precision Cutting
Our styrofoam cutting machine delivers ±0.3–0.5mm cutting precision through a high-torque stepping motor drive system and precision square rail guides
High Cutting Speed
The wide speed range allows operators to select the optimal speed for different foam densities-slower for high-density materials and faster for standard
Premium NiCr 80/20 Cutting Wire
NiCr 80/20 nickel-chromium alloy cutting wire (Cr20Ni80), offering superior resistance to oxidation and high-temperature stability
High-Capacity Multi-Tap Transformer
For wholesalers handling high-volume orders of standardized products, this feature dramatically increases batch output and reduces per-unit production cost
Intelligent Control System
The system features stroke protection, power-off memory, reverse cut, rotation, mirror symmetry, and backlash compensation functions
Heavy-Duty Rigid Structure
The machine frame is constructed from heavy-duty steel with a stable aluminum frame for the moving parts, ensuring high stability and accuracy
why choose us
Quality Assurance
ISO 9001:2015 certified CE certified – compliant with EU Machinery Directive
Fast Logistics
Factory located in Hangzhou, just 2 hours from Shanghai Port
After-Sales Support
On-site installation & commissioning Operation & maintenance training
Flexible Payment
TT, L/C at sight. Trade terms: EXW, FOB Shanghai, CIF.
