ICF Mould With ETPU Shape Mould Machine
video
ICF Mould With ETPU Shape Mould Machine

ICF Mould With ETPU Shape Mould Machine

The foam molding machine system adopts multiple heating methods, adopts the solid and moving mould balancing valve system, controls the instrument and controls the valve parts to complete the circulation, and further saves the steam of the machine. The unstable factors of product quality caused by unstable steam source are solved and the quality is greatly improved. The steam and cooling water valves adopt imported components. The operation is safe and the performance is stable. One person can operate 2-3 machines in the foam molding machine. The use of an additional device on a rotary table (ETPU foam foam cutting machine) is generally used for profiling processing, and also for cutting out rotations, including spheres.
Send Inquiry
Chat Now
Product Details

Hangzhou Epsole Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of icf mould with etpu shape mould machine in China. We warmly welcome you to buy high quality icf mould with etpu shape mould machine for sale here from our factory. Good service and reasonable price are available.





ICF (Insulated Concrete Forms) is widely used in the construction industry for constructing durable and energy-efficient buildings. The ICF moulds used in the production process are crucial components that determine the overall quality and performance of the final product. To ensure the top-notch quality of the ICF moulds, manufacturers have started using ETPU (Expanded Thermoplastic Polyurethane) shape mould machines that offer exceptional benefits.

The ETPU shape mould machine is a cutting-edge technology that is highly efficient and productive. It offers superior precision and flexibility in the design and production of complex ICF mould shapes, enabling manufacturers to meet the unique requirements of their customers. The advanced technology used in the machine ensures that the ICF moulds produced are of the highest quality and consistency, making them suitable for use in the construction of high-performance buildings.

The use of ETPU shape mould machines reduces the production time and costs involved in the manufacturing of ICF moulds. The machines are designed with automation features that enable them to operate continuously, with minimal maintenance and supervision. This results in increased productivity, efficiency, and profitability for ICF manufacturers.

Furthermore, the use of the ETPU shape mould machine is environmentally friendly as it reduces the amount of waste generated during the production process. The machines use recyclable materials, and the production process is designed to minimize the environmental impact.

In conclusion, the use of ETPU shape mould machines in the production of ICF moulds offers numerous benefits that are essential for the growth and success of the construction industry. The technology ensures that ICF manufacturers produce high-quality and energy-efficient products that meet the unique needs of their clients. Additionally, the machine's efficiency and automation features reduce production costs and time, increasing profitability, and sustainability.

2

Machine Type SMED ETPU Shape Moulding machine
Model ESS1214M ESS1417M ESS1915M
Data unit
Overall mm 5363*3310*4852 5363*3610*5152 5363*3710*5352
Mould size mm 800*1300 1200*1400 1500*1900
Product high mm 350 350 350
Move Distance mm 1200 1200 1200
Rod Diameter mm 80 80 100
Quantity pcs 4 4 4
Hopper Capacity L 145 145 145
Quantity pcs 2 2 2
Steam Machine Inlet DN 100 100 100
Mould Inlet DN 50*2 50*2 50*2
Pressure bar 6 6 6
Consumption Kg 4~5 4~5 4~5
Cooling Machine Inlet DN 80 80 80
Mould Inlet DN 50 50 50
Pressure bar 4 4 4
Consumption Kg 0~6.28 0~6.28 0~6.28
Vacuum Connector   100 100 100
Drainage L/h 100 100 100
Air Low DN 65 65 65
bar 4 4 4
High DN 50 50 50
bar 6 6 6
Consumption m³ 0.3~0.6 0.3~0.6 0.3~0.6
Hydraulic Motor Kw 7.5 11 11
Capacity L 400 400 400



3 4



ETPU is polyurethane thermoplastic foamed particles.

After the ETPU particles are preheated under pressure and heated, they expand like "popcorn". It has excellent resilience, environmentally friendly and efficient processing, able to adapt to various temperatures, more gentle and comfortable touch; excellent aging resistance and weather resistance, excellent physical resilience and structure will not be damaged by external forces for a long time.

Efficient vacuum cooling system with spray nozzle, independent of the drainage system, greatly reducing vacuum time;

The L shape vacuum tank is filled with multiple layers of stainless steel, making the contact point larger, and therefore the cooling time shorter, more efficient and more economic.

The closed constant pressure foamng barrel features of high heating efficiency and saves stem. The foaming machine has a complete faultself-diagnosis and motor protection system to ensure the safe operation and protection of the equipment

7

8

9

10
